Specifications

Dimensions

Terminal H / W: 97 / Ø321 mm (incl. mounts) 3.82 / Ø12.7 inches

Weight

Terminal: 3.6kg / 7.9lbs

Global Services

Voice: 4 kbps AMBE+2

Premium voice: 64 kbps (@elevation>45°)

Standard IP: Up to 200 kbps

Streaming IP: 16, 32 kbps

SMS: 160 characters

Guaranteed service: Above 20° elevation

Limited service: 5°-20° elevation

Inmarsat frequencies: 1518.0 - 1525.0 MHz (Rx) (EMEA) 1525.0 - 1559.0 MHz (Rx) 1626.5 - 1660.5 MHz (Tx) 1668.0 - 1675.0 MHz (Tx) (EMEA

Interfaces

1 x WLAN interface

Standard: 802.11 b/g

1 x LAN interface

Data rate: 10/100 Mbps

Combined DC power and Ethernet connector

Combined connector providing DC power input, ignition and Ethernet connectivity

Hybrid cable, wires: Power 2, Ignition 1, Ethernet 4 + 1 (shield)

Power

DC input range: 10.5-32VDC

Power (max) @10.5-32V.: 35W

General

User Interface: Status LED

Web interface

Factory default reset

Languages: UK, FR, DE, ES, RU, CN and PT

Approvals: CE, GMPCS, FCC

Inmarsat Class 12 and Inmarsat M2M Type Approval

Environmental conditions

Temperature

Operational: -25 to +55°C / -13 to 131°F

Survival: -40 to +80°C / -40 to 176°F

Storage: -40 to +85°C / -40 to 185°F

Relative humidity: 95% non-condensing

at +40°C / +104°F

Water and dust (IP-rating)

Terminal: IP66
